VRK-2400 Autorefractor con Queratometro digital VIEW con pantalla LCD color impresora

Descripción del producto

VRK-2400 Autorefractor con Queratometro digital VIEW con pantalla LCD color impresora

VRK -2400 ESPECIFICACIONES TECNICAS EN INGLES

helps accurate examination
more comfortably.

VRK-2400
auto ref-keratometer
VRK-2400
design
specifications
function
Auto ref-keratometer
VRK-2400 supports various and fast examination mode to diagnose
Refractometry and various convenient function.

Variable examination mode
VRK-2400 has Refractometry function (REF Mode),
Keratometry function (KER Mode),
Keratometry&Refractometryfunction (K/RMode),
contact lens based curve function (CLBC Mode),
Auto Start and so on.
Additional
By freeze function, diameter of cornea, pupil
or hard contact lens can be measured.
Wide range of measurement
VRK-2400 provides range of refraction for
SPH from -25D to +22D, and radius of
curvature from 5.0mm to 10.2mm

Sophisticated and
modern design
With the black and white color, it can be assimilate at your refraction room.
VRK-2400
SPECIFICATION
Refractometry

Vertex Distance(VD) 0.0, 12.0, 13.5, 15.0

Sphere Power(SPH) -25.00 ~ +22.00D (at the vertex distance of 12 mm)
(Increments selectable between 0.12 and 0.25 D)

Cylinder Power(CYL) 0.00~ ±10.00D (Increments selectable between 0.12 and 0.25 D)

Axis(AX) 1~180˚ (Increments: 1˚)

Cylinder Form -,+,MIX

Pupil Distance(PD) 10~88mm

Minimum Pupil Diameter ∮2.0mm

Keratometry

Radius of Curvature 5.0~10.2mm (Increments: 0.01 mm)

Corneal Power 33.00 ~ 67.50D (when cornea equivalent refractive index is 1.3375)
(Increments selectable from 0.05, 0.12, 0.25 D)

Corneal astigmatism 0.00 ~ -15.00D (0.05 / 0.12 / 0.25D 단위)

Axis 1 ~ 180˚ (Increments: 1˚)

Corneal Diameter 0.8 ~ 14.0mm (Increments: 0.1 mm)

Memory of Data 10 measured value for each right and left eye

Internal Printer Uses thermal line printer

Monitor 5.7-inch TFT LCD monitor

External Interface

VGA Video Output: Connected with Monitor via VGA Cable.
RGB video signal plus option H and V sync

RS-232 Interface Connected with PC or PAV-6100 via RS232 Cable.
RS232 Signals are r± 15[V] with Maximum 100mA

USB B Type Connected with PC via USB Cable.
USB Signals are 5.00±0.25[V] with Maximum 500-900[mA]

Environmental requirements:

Operation Temperature: +10 to +40℃

Humidity: 30 to 85% RH

Atmospheric pressure : 70 to 106 kPa

Storage and Transportation Temperature: -10 to +55℃

Humidity: 10 to 95% RH

Atmospheric pressure : 50 to 106 kPa

Power supply AC100-240V, 50/60Hz

Power consumption 40 ~ 55 VA

Size 273(W) ´ 501(D) ´ 473(H) mm

Weight Approximately 20kg
